Classification : Bottom Sealing Bag
Country: Taiwan
Phone: 886-5-2358505
Fax: 886-5-2359463
Contact Person: Zoe Tsai
● Double layer for 4 lanes in total.
● Uses servo motor for feeding, with stable sealing abilities, and fast on speed change. Easy to change bag size, and size error is permissible.
● The machine stops as soon as materials are used up or the temperature drops 4-8 degree, or bags become superimposed.
● With conveyor.
● Hot pin positions can be moved freely.
● By adjusting the connector between back feeding rollers to enable 2-lane or 4-lane production.
● Uses servo motor for feeding, with stable sealing abilities, and fast on speed change. Easy to change bag size, and size error is permissible.
● The machine stops as soon as materials are used up or the temperature drops 4-8 degree, or bags become superimposed.
● With conveyor.
● Hot pin positions can be moved freely.
● By adjusting the connector between back feeding rollers to enable 2-lane or 4-lane production.
| MODEL | BJA2+S 28"x 42" | BJA2+S 32"x 48" | BJA2+S 40"x 60" |
| Max. Cutting Width mm (inch) | 660(26") or 304(12") x 2 | 762(30") or 355(14") x 2 | 965(38") or 457(18") x 2 |
| Max. Cutting Length mm (inch) | 1(42") | 1.2(48") | 1.5(60") |
| Thickness (micron/sheet) | 9-50 | 9-50 | 9-50 |
| Length Tolerance (mm) | ±1 | ±1 | ±1 |
| Production Rate (pcs/min) | max. 140 | max. 140 | max. 140 |
| AC Driving Motor (HP) | 2 | 2 | 2 |
| Heater Capacity (kW) | 4.2 | 5 | 5.6 |
| Power Required (kW) | 9.9 | 10.7 | 12.3 |
| Machine Dimensions (L*W*H cm) | 450x130x190 | 450x140x190 | 480x160x190 |
| Machine Weight (kg) | 1400 | 1600 | 1900 |
| Packing Dimensions (L*W*H cm) | 252x161x215 | 252x173x215 | 261x222x215 |
| Gross Weight (kg) | 1650 | 1900 | 2250 |
| ● Correct specifications depend on the actual model. All specifications are subject to change without prior notice. | |||
