Classification : Powerful Crusher
Country: Taiwan
Phone: 886-4-26821888
Fax: 886-4-26819777
Contact Person: Jessica Liu
The round and hollow frame structure alows big processing volume. The capacity is 3 times more than the average type crushers.
- The round and hollow frame structure alows big processing volume. The capacity is 3 times more than the average type crushers.
- Well-designed angle cutters enables you to properly monitor and run easily the machine making the output estimate for other process.
- With water cooling system and clearance between cutters makes it easy for heat dissipation that helps reduce damage effect between bearings and machine body.
- Hardened crusher blades.
- The adapted ball bearings provide strong friction resistance, good centering and anti-vibration.
Model |
GD-A-210 |
GD-A-212 |
GD-A-215 |
GD-A-218 |
GD-A-220 |
GD-A-225 |
Rotary Diameter |
||||||
Size |
Ø200mm |
Ø260mm |
Ø298mm |
Ø330mm |
Ø380mm |
Ø380mm |
Input Size |
||||||
Size |
270mm*160mm |
315mm*185mm |
400mm*240mm |
463mm*274mm |
536mm*286mm |
636mm*290mm |
Motor |
||||||
5HP | 7.5~10HP | 15~20HP | 20~25HP | 25~30HP | 30~50HP | |
Rotary Cutter |
||||||
Quantity |
3pcs |
3pcs |
3pcs |
3pcs |
3pcs or 6pcs |
3pcs or 6pcs |
Stationary Cutter |
||||||
Quantity |
4pcs |
4pcs |
4pcs |
4pcs |
4pcs |
4pcs |
Capacity |
||||||
kg/hr |
150~300 |
200~500 |
300~600 |
400~700 |
500~900 |
600~1200 |
*The product line can be made to spec meeting customer needs.
*Equipment specifications are also constanly updated. You are welcomed to contact us for details.
